DIMENSIONS
Length2,410
mm
Seat Height,
Unladen 705
mm
Ground Clearance105
mm
Rake (steering head)
(deg)34
Trail142
mm
Wheelbase1,700
mm
Tyres, Front
Specification120/70ZR-19
60W
Tyres, Rear
Specification240/40R-18
79V
Fuel Capacity18.9
l
Oil Capacity
(w/filter)4.7
l
Weight, As
Shipped292
kg
Weight, In
Running Order307
kg
ENGINE
Engine Liquid-cooled,
Revolution®, 60° V-Twin
Bore105
mm
Stroke72
mm
Displacement1,247
cc
Compression Ratio11.5:1
Fuel SystemElectronic
Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary DriveGear,
117/64 ratio
Gear Ratios
(overall) 1st10.969
Gear Ratios
(overall) 2nd7.371
Gear Ratios
(overall) 3rd5.9
Gear Ratios
(overall) 4th5.095
Gear Ratios
(overall) 5th4.563
Gear Ratios
(overall) 6thN/A
CHASSIS
ExhaustSatin
chrome, dual side exhaust system with black end
caps
Wheels, Optional
Style Type N/A
Wheels, Front Type Black,
5-Spoke Cast Aluminum
Wheels, Rear Type Black,
5-Spoke Cast Aluminum
Brakes, Caliper
Type4-piston
front and rear
PERFORMANCE
Engine Torque
Testing MethodEEC/95/1
Engine Torque 115
Nm
Engine Torque (rpm)6,500
Lean Angle,
Right (deg.)32
Lean Angle, Left
(deg.)32
Fuel Economy: Combined
City/Hwy6.3
l/100 km
